Video matrix selection considerations
Incorporating the strengths of both confectioned copper foil and Evan film, our sensor materials are an industry breakthrough for high-level precision sensors. Engineered with a fully sealed laminated foil and polyimide film structure, these materials offer a dual advantage of temperature and creep self-compensation, ensuring relentless accuracy over time. Strain Gauges,Accuracy Load Cell,Parallel Grid Strain Gauge,Pressure Sensor Use Gauges Zhejiang Nanhua Electronic Technology Co., Ltd , https://www.nhloadcell.com
Select <br> <br> matrix interface interfaces with different forms of the matrix switcher, to the video signal as an example, a common form of interface: D-15 type connector, BNC interfaces, the RCA (RCA) interface, DVI Interface , S-VIDEO interface, RJ45 interface and so on. In engineering applications, a specific device interface format must be selected according to the format of the switching signal and the actual transmission needs. For example: computer video signal selection D-15 type interface; industrial and military video signals to select BNC interface; home entertainment and civilian video equipment Lotus interface; computer digital video DVI interface; network digital video RJ45 interface, HDMI digital high-definition Dedicated interface, etc. The interface selection must be accurate, as far as possible without adapters to convert the interface form, resulting in unnecessary signal loss, affecting the project quality.
<br> <br> matrix bandwidth selecting different signals having different bandwidths, the bandwidth of the audio signal is low, above the audio bandwidth of the video signal, VGA signal is higher than the bandwidth of the video signal. The current high-definition video signal has a very high bandwidth. Therefore, in the selection of the bandwidth of a matrix product, a high-bandwidth high-definition video matrix should be selected as much as possible. For computer VGA signals, the higher the resolution, the shorter the signal transmission distance and the higher the required bandwidth of the matrix. When choosing a matrix switcher, bandwidth is a problem that needs careful consideration. In order to transmit image signals clearly, it is highly recommended to purchase a high-bandwidth HD matrix for the future expansion of high-definition image equipment.
Select <br> <br> matrix compatibility matrix audio and video works, the core equipment, a variety of signals from different sources of equipment, required to have a high compatibility matrix. This requires that the matrix has a higher input amplitude range at the input, the output has a certain drive capability, and the impedance matching between the devices is appropriate.
